TBS6104 DVB-T Quad Modulator Card

Model#: TBS6104-DVBT
List Price: US$799.00
Price:
US$
679.00
15%
Save:US$120.00 ( 15% OFF )
Weight: 750 g(s)
Ship From: China
You will earn 679 Points for buying this product. How to Use ?
Qty:
-
+
Unit(s)

Options:

System options:

If you need more, please Contact us directly.

Description:

This is a DVB-T modulator card, it works as a DVB-T signal generator and supports 4- frequencies DVB-T transmission.This quad card can convert transport stream to DVB-T signal, for example, you can use a TBS DVB-S2 TV tuner card to receive satellite TV channels and use this modulator card to convert the DVB-S2 TS to DVB-T signal  at the same time, a modern TV or Set-Top-Box with DVB-T tuner integrated can be used to receive the terrestrial signal easily from the modulator card.

This card provides a very cost-effective solution to transfer other digital resources, like DVB-S2/S, DVB-C, ISDB-T, ATSC or even IPTV resources into an existing DVB-T system in hotels, hospitals, or dormitories.

Specifications

Possible Inputs DVB-S2/S, DVB-C, ISDB-T, ATSC or IPTV resources
Outputs DVB-T in 4 frequencies
Frequency range 50 ~ 950 MHz
Channel bandwidth 6,7,8 MHz
Level 5-120
FFT 2K,8K
FEC QPSK,16QAM,64QAM
Code rate 1/2,2/3,3/4,5/6,7/8
Guard interval: 1/4,1/8,1/16,1/32
Max bit rate 27Mbps/per frequency
Working Temperature -40°~85°
Power 10W
System Requirements Linux
Available PCI Express x1, x4, x8 or x16 slot
Package Contents 1 * TBS6104 DVB-T Quad Modulator Card
1 * low profile bracket
F-IEC connector
Card Size Gift Box Size Gross Weight
130mm * 68.7mm 200*138*50mm 0.5kg
∧
