TBS2605 is a professional 4K/H.265 HDMI encoder, which is also our newest HD audio & video encoding device with powerful functionality. It supports real 4K, up to max 3840 x 2160P@30fps.

TBS2605 HDMI Video encoder not only supports 2 channels 4K or 5 channels H.265 encoding, but also supports multiprotocol output. Each channel supports HTTP/HLS/RTMP/RTSP/UDP protocols outputting simultaneously, which is ideal for the customers who need to output with different protocols.

TBS2605 is coupled with Web UI managing system and telnet remote access, and equipped with video mix and split screen display function, which provide users flexible choices to control the encoder at anytime and anywhere.

The product can be applied to education, health care, IPTV, conference, remote education, news interview, banking, transportation and other industries.

  • 5 x HDMI 1.4 inputs
  • supports Network streams in for video mix or protocol converting
  • H.265 and H.264 Encoder
  • Multiple protocol outputs: HTTP/HLS/RTMP/RTSP/UDP (Multicast, Unicast)
  • Support video mix and split screen function ( 1, 3, 9 screens for your choices)
  • Support H.264/H.265 network streams input for video mix or converting to required IP streams output
  • Support OSD function (logo, text, mosaic )
  • Single LAN port output and management
  • WEB UI Management and Telnet remote access
  • LCD display for IP , encode status and bitrate info

Why you choose TBS2605 ?

Supports 5 channels H.265/h.264 encode or 2 channels 4K encode

  • 3840x 2160P@30fps. Max Resolution (4K/UHD)
  • Real-time encoder supporting resolutions up to 4K with HEVC and H.264 encoding.
  • Efficient encoding leads to bandwidth savings, even at high resolutions.
  • Ideal for future-proofing workflows that need to move to 4K UHD and for those that require the highest video quality.

Supports 5 channels H.265/h.264 encode or 2 channels 4K encode

Multiprotocol output

  • Compliant with HTTP/HLS/RTMP/RTSP/ UDP protocols
  • Each channels have multiple protocols for outputting

Video mix function, multiplex and split screen display

Video mix function allow you to choose the channels from HDMI and IP , merges them together and provide one new TS, then decode them , with the screen display function , offer users flexible choices to control and monitor the channels at anytime and anywhere.

Single LAN port output and management

TBS2605 supports multiple HDMI inputs with only one LAN port for output and management, which greatly save source and space for you. And reliable Web UI let you easy to setup and manage.


IPTV - Topology

Video Mix and monitoring - Topology


Model Number TBS2605
Video Input 5x HDMI 1.4
Audio Input HDMI embedded audio
Resolution Input: 3840x2160, 3392x2208, 2592x1520, 2560x1440, 2304x1296, 1920x1080, 1680x1056, 1280x720, 1024x576, 850x480, 720x576, 640x480, 360x240, and etc.
Output: 3840x2160@30fps, 1920x1080@60fps, 1680x1056, 1280x720, 1024x576, 850x480, 720x576, 640x480, 360x240, and etc.
Encode H264 base line, H264 Main, H264 High, H265 Main
Data Rate 0.5Mbps~20Mbps
Rate Control CBR/VBR
Encoding AAC, MP3
Sampling rate: 16K, 32K, 44.1K, 48K
Sampling precision 16 bit
Data Rate 64Kb/s ~ 256Kb/s
Network Stream Input
Video H.264 / H.265
Audio MPEG 1/2, MP3, AAC
Protocol HTTP / RTSP / RTP / UDP (multicast, unicast)
Ethernet / RJ45 1000 Base-T Ethernet interface
Control WEBUI
General Spec.
Dimension 185 * 119 * 36mm(length, width, height)
Power less than 15W
