TBS6905 DVB-S2 Quad Tuner PCIe Card

  • item#: TBS6905
  • Price:
    249.99
  • Start from: 1 Unit(s)
  • Weight: 400 g(s)
  • Ship From: ChinaEurope
  • You will earn 250 Points for buying this product. How to Use ?
Qty.Range(unit) Price(per unit) Discount
1 US$249.99 No
2-5 US$244.56 2.174%
6+ US$239.12 4.348%
10+ Please contact us.

  • Shipping Methods
  • Payment Methods

Relative Products

Description:


TBS6905 is a successor of TBS6985,it's a PCI Express interface digital satellite TV Tuner card with four tuners for watching and recording FTA (Free to Air) satellite TV on PC. The four tuners allow you to watch TV channel from one transponder/satellite while recording three other channels from different transponders/satellites in the same time. TBS team has developed both Windows BDA driver and Linux driver up to the latest kernel for this quad tuner card Tested on. It’s compatible with Windows 7 Media Center and popular software like MediaPortal, DVBlink, DVBDream, DVBViewer, ProgDVB, Skynet, TSreader, XBMC, MythTV.



TBS6905 PCI-E DVB-S2 Four Tuner TV card is designed to fulfill the needs of watching/recording multiple satellite TV channels on PC simultaneously. It’s the successor of TBS6985. With Single tuner TV card, you’re limited to watch or record one satellite TV channel at one time only.



While with this TBS6905 quad tuner TV card, you can watch one channel and record three other channels at the same time.Even more if you want to make full use of the recording power of TBS6905, you may record four whole TS (Transponder Stream), one of which could contains maximum ten, twelve SD or HD TV channels into your PC hard disk, in other words, you will be able to record up to 48 channels with TBS6905 in the same time. This feature contributes a lot especially when you are building up HTPC or IPTV streaming server.



You can use TBS6905 Quad Tuner PCIe Card to watch any free to air satellite TV programs in your region including Freesat HD if you are located in the UK. By using appropriate software, e.g. MediaPortal and its’ plugins, you can stream satellite TV contents to your iPhone, iPad or iPod.



Main Features:

Quad tuner DVB-S2/S transponders receiving

Multi Input Stream support

Generic stream mode Support

Up to 190 Mbit/s channel bit rate capture

Wide range symbol rates support from 1Msps to 45Msps

High-speed data download via satellite

Unicable/one cable compatible

Blindscan

High reliability



Applications:

HTPC

IPTV streaming server



Specifications:

Receiving frequency: 950~2150 MHz tuning range

Input level: -69~-23dBm

Quad channels DVB-S2/DVB-S 8PSK QPSK Demodulator



Symbol rate:

-Maximum symbol DVB-S2 rate limitations (Msymb/s)

Msymb/s Demod LDPC Single Dual
QPSK 67.5 135 67.5 67.5
8PSK 67.5 90 67.5 45
16APSK 67.5 67.5 67.5 33.7
32APSK 67.5 54 54 27



-DVB-S

QPSK+1/2, 2/3, 3/4, 5/6, 7/8

Support Data Burst & Tone Burst

Support DiSEqC2.X and Motor

Standard profile TV card size: 145*92.3mm (length x height)

Power consumption: 0.66W ~ 33.13W

Operating temperature: -10°C ~ 70°C



System Requirements:

Windows 2000/XP/Vista/7/8/10 or Linux

DirectX9.0 or later version

Available PCI Express x1, x4, x8 or x16 slot

Satellite dish and LNB



For DVB-S:

1GHz CPU or above

256MB RAM or above

Graphic card with at least 16MB RAM



For DVB-S2 HDTV:

Dualcore CPU

1GB RAM or above

Graphic card with at least 64MB RAM



Package Contents:

1 x TBS6905
1 x DC line


Product Reviews:

Average rating:

5 (based on 10 reviews)

Recent Reviews

  • By Jason
  • Verified Buyer
  • Feb 22, 2016

One question can I use this card with hp z800 workstation? And I use cccam or oscar cam wil ik get scrambeld channels?

Was this review helpful?

(0)|(0)
Reply
Dear Jason,

One question can I use this card with hp z800 workstation? (Yes)
And I use cccam or oscar cam wil ik get scrambeld channels? (Yes)

Thanks.

Best Regards!

BUYDVB Online Store
By hellen Feb 25,2016
  • By Adrian
  • Verified Buyer
  • Feb 12, 2016

Hi, i'm building a iptv server with tvheadend. How many streams can download from ONE transponder with this card?
For Ex: Some satellite have 49 channels on one transponder and 48 channels on another transponder. This card work fine to download both transponders simultaneously?
Another questions, do you send to Argentina over DHL? Can you declare a lower value when you send the card?
Thanks.

Was this review helpful?

(0)|(0)
Reply
Dear Adrian,

Thanks for your message at first.

i'm building a iptv server with tvheadend. How many streams can download from ONE transponder with this card?
For Ex: Some satellite have 49 channels on one transponder and 48 channels on another transponder. This card work fine to download both transponders simultaneously? (Yes)
Another questions, do you send to Argentina over DHL? (Yes) Can you declare a lower value when you send the card? (Yes)

Best Regards!

BUYDVB Online Store
By hellen Feb 22,2016
  • By Chaudhry
  • Jan 21, 2016

Hi

Does the TBS6905 supports signals ( Turbo 8PSK )

Best Regards!

Was this review helpful?

(0)|(0)
Reply
Dear Chaudhry,

Sorry that TBS cards don't support turbo code at present.

Best Regards!

BUYDVB Online Store
By hellen Jan 29,2016
  • By Sfox
  • Dec 23, 2015

Hi

Does the TBS6905 supports signals ( CCM, VCM,ACM )

Best Regards!

Was this review helpful?

(0)|(0)
Reply
Dear Sfox,

TBS6905 doesn't support signals ( CCM, VCM,ACM ). But our TBS6983 and TBS6908 support CCM, ACM, VCM, Multi Input Stream, 16APSK,32APSK,Generic Stream Mode.

Best Regards!

BUYDVB Online Store
By hellen Dec 31,2015
  • By Geo
  • Verified Buyer
  • Dec 07, 2015

I use moipro and I think the format for this card also will be udp output right? How can it be used for streaming since all IP streaming softwares used for Streaming uses rtmp and there is no way to stream in RTMP right?
Wowza and all other softwares uses rtmp which is not provided as an output. So how do we stream to the net since udp data is huge for live streaming?

Was this review helpful?

(0)|(0)
  • By fmm
  • Verified Buyer
  • Nov 26, 2015

Hello,

is it possible to watch 4 4:2:2 (or not) channels simultaneously using 4 distinct instances of DVBviewer, 1 for each tunner.

Was this review helpful?

(0)|(0)
Reply
Dear Sir,

Yes, it is possible to watch 4 4:2:2 (or not) channels simultaneously using 4 distinct instances of DVBviewer, 1 for each tunner :)

Best Regards!

BUYDVB Online Store
By hellen Nov 27,2015
  • By Mustafa
  • Aug 24, 2015

Hi,

I am about building a new iptv headend, and my plan is to use couple of dvb s2 quad cards (2 or 3) to cover all transponders within a network.
my question is: how many streams (per transponder) can this card process?
could it process all the streams within the tuned transponder?
what is the max. raw bandwidth this card can handle?

Regards
Mustafa

Was this review helpful?

(0)|(0)
Reply
Dear Mustafa,

Thanks for your questions. We recommend you email to TBS support side: support@tbsdtv.com for more details.

Best Regards!

BUYDVB Online Store
By hellen Aug 26,2015
  • By mk-ned
  • Jul 26, 2015

Нello

is it possible receive T2-MI channels with this card?
and
is it possible to install it beside TBS6982?

Best Regards!

Was this review helpful?

(0)|(0)
Reply
Dear Sir,

Thanks for your questions. TBS6905 is DVB-S2 card. It can not be used for DVB-T2 signal.

is it possible to install it beside TBS6982? (Of course, you can.)

Best Regards!

BUYDVB Online Store
By hellen Jul 27,2015
  • By diop
  • Verified Buyer
  • Jul 09, 2015

Can we use LNB UNICABLE with TBS 6905

Was this review helpful?

(0)|(0)
Reply
Dear Diop,

Yes, you can use LNB UNICABLE with TBS 6905.

Thanks.

Best Regards!

BUYDVB Online Store
By hellen Jul 10,2015
  • By Olexiy
  • Verified Buyer
  • Jun 02, 2015

Нello! Are your sure that it is not mistake?

Qty.Range(unit) Price(per unit) Discount
1 US$229.99 No
2-5 US$249.99 ??? -8.70% ????

Best regards, Olexiy

Was this review helpful?

(0)|(0)
Reply
Dear Olexiy,

Sorry that we made a mistake. We have updated the price on online store. You can place an order now.

Thanks for understanding.

Best Regards!

BUYDVB Online Store
By hellen Jun 03,2015
